6.5” 640 x 480 Resolution, 800nits Panel
Intel® Celeron® J6412 onboard Processor
SECC Front Panel + Aluminum Back Cover
IP54 Rated Front Panel
Support 5-wire Resistive Touchscreen
Support VESA and Panel Mounting
特点
应用
HMI Solution
Embedded Panel PC on the chassis
Digital Transformation
ATM / Self-service / Kiosk Application
Industrial Automation
|
Model |
PPC-664R |
||
|
Processor System |
CPU |
Intel® Celeron® J6412 Processor |
|
|
Frequency |
up to 2.60GHz |
||
|
BIOS |
UEFI |
||
|
TPM |
fTPM |
||
|
Memory |
Technology |
Dual Channel DDR4 3200MHz (un-buffered and non-ECC) |
|
|
Max. Capacity |
Support up to 32GB |
||
|
Type |
2 x 260-pin SO-DIMM |
||
|
Panel |
Panel Type |
6.5" LCD |
|
|
Aspect Ratio |
4:3 |
||
|
Resolution |
640 x 480 |
||
|
Brightness |
800cd/m² |
||
|
Color |
16.2M |
||
|
Contrast Ratio |
600:1 |
||
|
Viewing Angle |
160 (H) x 140 (V) |
||
|
Backlight MTBF (typ.) |
50,000Hrs |
||
|
Touchscreen |
Touchscreen Type |
5-wire Resistive |
|
|
Surface Hardness |
3Mohs |
||
|
Transparency |
80% (±3%) |
||
|
I/O Interface |
Ethernet |
2 x GbE LAN Ports (Intel® I211-AT) |
|
|
HDMI |
2 x HDMI 2.0, Max Resolution 4096 x 2160 |
||
|
Serial Port |
Optional for 2 x RS232/422/485 |
||
|
USB |
4 x USB3.2 Gen1 |
||
|
Audio |
1 x Line-out |
||
|
Storage |
2.5" SSD/HDD |
Internal 1 x 2.5” SSD/HDD |
|
|
M.2 |
Internal 1 x M.2 2280 M-Key (PCIe x2, SATA) |
||
|
Expansion |
Mini-PCIe |
1 x Full-Size Mini-PCIe with SIM slot (PCIe, USB2.0 and SIM) |
|
|
M.2 |
1 x M.2 2280 M-Key (PCIe x2, SATA) |
||
|
Power |
Power Mode |
AT/ATX |
|
|
Power Supply Voltage |
12~36V DC Input |
||
|
Power Connector Type |
1 x DC Power Connector, 1 x 2-pin Terminal Block |
||
|
Environment |
Operating Temperature |
-20C ~ +60°C |
|
|
Storage Temperature |
-30C ~ +70°C |
||
|
Humidity |
10% ~ 95%, Non-condensing |
||
|
Vibration |
2.16Grms, 5 - 500Hz, 0.5hr/axis |
||
|
Shock |
20G, half sine, 11ms |
||
|
General |
Certification |
CE/FCC Class A |
|
|
Ingress Protection |
Front Panel IP54 |
||
|
Material |
SECC Front Panel + Aluminum Back Cover |
||
|
Mounting |
VESA (100 x 100mm) / Panel |
||
|
Dimensions (W x H x D) |
191.4 x 158.2 x 73mm |
||
|
Net Weight |
1.55kg |
||
|
Operating System |
Windows 10 IoT, Windows 11 (IoT/Professional), Linux |
||
Ordering Information
Part No.
Description
PPC-664R
6.5" 4:3 (640 x 480), 800nits,
5-wire Resistive Touch, SECC, Intel® Celeron® J6412, 2 x GbE, 2 x HDMI, 4 x
USB3.2, Line-Out, 12~36VDC (2-pin Terminal Block)
Packing List
Description
1 x PPC-664R
Optional Items
Part No.
Description
EA-PS-60W12VTB2xx-0211
Adapter AC/DC 12V 5A 60W with 2-pin Terminal Block Plug 5.0mm Pitch
27-x301000003-CA
Power Cord, 3-pin US Type, 180 cm
27-x301010005-CA
Power Cord, 3-pin EU Type, 180 cm
EA-AWD-4G003xxxxx-0011
4G (LTE) EG25-G + 2 Antennas, Full Size (for Global)
EA-AWD-WF007xxxxx-0010
Wi-Fi 802.11 a/b/g/n/ac/BT5.0 (2T2R) + 2 Antennas (Dual Band), Mini PCIe Half Size
