BPC-5097

Model

BPC-5097-1A1

Processor System

CPU

 Intel® Alder Lake-N N97 Processor

Frequency

 up to 3.60GHz

BIOS

 AMI SPI 256 Mbit

TPM

 Intel® PTT (supports to TPM2.0)

Memory

Technology

 Single Channel DDR5 4800MHz

Max. Capacity

 Support up to 32GB

Type

 1 x 262-pin SO-DIMM

Display

Graphics Engine

 Intel® UHD Graphics

Multiple Display

 1

HDMI

 1 x Lockable HDMI 2.0b, Max resolution up to 4096 x 2160@60Hz

I/O Interface

USB

 3 x USB2.0

Serial Port

 1 x RS-232/422/485 (supports 5V/12V/RI) , 3 x RS-232 (supports 5V/12V/RI)

Ethernet

 2 x GbE LAN (Intel® I210-AT) (M12 Connector)

GPIO

 16 x isolated DI and 16 x isolated DO channels

Storage

2.5” HDD / SSD

 1 x 2.5” SATA SSD

M.2

 1 x M.2 M-key 2242/2280 with PCIe Gen3 x1 and SATA3 for SSD

Expansion

M.2

 1 x M.2 E-Key 2230 with PCIe Gen3 x1, USB 2.0 and CNVi for Wireless

 1 x M.2 B-Key 3042/3052 with PCIe Gen3 x1, USB 2.0 and SIM for 4G/5G

SIM Socket

 1 x SIM socket connected to M.2 key B

Power

Power Mode

 AT/ATX

Power Supply Voltage

 9-36V DC Input

Power Connector Type

 1 x DC Power Connector, 1 x 2-pin Terminal Block

Mounting

Type

 Wall Mount

Environment

Operating Temperature

 -20C ~ 60°C

Storage Temperature

 -30C ~ 70°C

Humidity

 0% ~ 90% (non-condensing)

Vibration

 1.5Grms, 5 - 500 Hz, 0.5 hr/axis

Shock

 50G, half sine, 11ms

Certification

 CE/FCC Class A

General

Thermal Dissipation

 Fanless System

Material

 Aluminum & SECC

Dimensions (W x D x H)

 238 x 245 x 68mm

Net Weight

 3.5kg

Operating System

 Windows 10 IoT, Windows 11 (IoT/Professional), Linux
